Mold Design Using NX 11.0

This textbook has been written with the intention of helping the readers effectively use the mold wizard tools such as gate, runner and various standard parts in NX. The users will be able to create mold design easily and effectively through some processes such as analysis and documentation which have been dealt in detail. Also, the chapters in this textbook are arranged in a pedagogical sequence that makes this textbook very effective in learning the features and capabilities of the software.

Chapter 1: Introduction to Mold Design and NX Mold Wizard Chapter 2: Part Analysis Chapter 3: Creating Parting Surface Chapter 4: Creating Core and Cavity Chapter 5: Adding Mold Base and Standard Parts Chapter 6: Creating Gate, Runner and Layout Chapter 7: Creating Sliders and Lifters Chapter 8: Creating Ejection and Cooling Systems Chapter 9: Creating Electrodes Chapter 10:  Documentation Index

Prof. Sham Tickoo
